Max kV |
450kV |
Max electron beam power |
450W |
X-Ray spot size |
80μm |
Geometric Magnification |
>15x |
Imaging System (Standard) |
Perkin Elmer 1620 Flat Panel Detector |
Imaging System (option) |
Perkin Elmer 1621 Flat Panel Detector Combined 2D/3D with Curved Linear Diode Array (CLDA) |
Manipulator |
4-axis (X, Y, Z, R) Option 5-axis |
Axes travel |
(X) 400 mm (Y) 600 mm (Z) 600 mm (Rotate) n*360° |
Max sample weight |
100kg (11 lbs) |
Cabinet dimensions (WxDxH) |
3,613 mm x 1,828 mm x 2,249 mm |
Weight |
14,000 kg |
